Fluke 417D Laser Distance Meter
Key features
- The Fluke 417D laser meter is accurate, durable, and easy to use—just point and shoot
- Instantly measure up to 40 m (131 ft.) with 1-button point-and-click
- Continuous measurement capable: adjusting as you move closer and farther from your target
- Quickly calculate area (sq feet/meters)
- 1-meter drop tested and IP54 rated: built to withstand rainy or dusty conditions
- Great for interior and exterior applications
22 people are viewing this right now
Guaranteed safe & secure checkout
Product details
Specifications
Shipping and Returns
Reviews
Questions
Product details
Product overview: Fluke 417D Laser Distance Meter
The Fluke 417D is accurate, durable, and easy to use—just point and shoot. The simple design and easy, one-button measurement operation allows you to minimize time spent measuring and maximize the reliability of measurements.
Additional Product Features:
- Large, 2-line illuminated LCD screen.
- Three different measurement tasks can be completed quickly and easily with one hand.
- The bright laser is clearly visible, so you can always see your target point even from a hard-to-reach spot or long distance.
- Designed for both indoor and outdoor applications.
- Operates with the Fluke durability and quality you expect.
- Protected by a 3-year warranty.
Specifications
| Measurement Specifications | |
|---|---|
| Typical Measuring Range | 0.2 to 40 m (0.6 to 131 ft) |
| Typical Measuring Tolerance | ±2.0 mm ±1.5 mm (±0.06 in) |
| Maximum Measuring Tolerance | ±3.0 mm (±0.12 in) |
| Accuracy (Up to 10 m) | ±2 mm |
| Display | 2-Line LCD Display |
| Display Resolution | 1 mm / 1⁄32 in |
| Display Illumination | Yes |
| Laser Spot Size | 6 mm / 30 mm / 60 mm (at 10 m / 40 m / 100 m) |
| Area Measurement | Yes |
| Measurement Units | m, ft/in, in |
| Auto Laser Shut-Off | 90 Seconds |
| Auto Power-Off | 180 Seconds |
| General Specifications | |
| Laser Class | Class II |
| Laser Type | 635 nm, <1 mW |
| Protection Rating | IP54 |
| Battery Type | 2 × AAA 1.5 V (NEDA 24A / IEC LR03) |
| Battery Life | Up to 3,000 Measurements |
| Dimensions (H × W × D) | 119 × 38 × 26 mm (11.9 × 3.8 × 2.6 cm) |
| Weight (Including Batteries) | 95 g (3.35 oz) |
| Drop Test | 1 m |
| Operating Temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Storage Temperature | -25 °C to 70 °C (-13 °F to 158 °F) |
| Maximum Relative Humidity | 85% RH (-7 °C to 50 °C) |
| Calibration Cycle | Not Applicable |
| Safety & Compliance | |
| Safety Standards | CAN/CSA-C22.2 No. 61010-1-04 UL 61010-1 (2nd Edition) ISA-82.02.01 IEC 61010-1:2001 EN60825-1:2007 (Class II) |
| Electromagnetic Compatibility (EMC) | IEC 61326-1:2006 |
| Measurement Notes | |
| Typical Accuracy | Based on 100% target reflectivity (white painted wall), low background illumination, at 25 °C. |
| Maximum Accuracy | Based on 10%–500% target reflectivity, high background illumination, and operating temperatures from -10 °C to +50 °C. |
| Distance Accuracy | 0.05–10 m: Stated tolerance (95% confidence) 10–30 m: Additional ±0.1 mm/m Above 30 m: Additional ±0.15 mm/m |
