NXN Series

Product details

KEY FACTS

• Frequency Range: 9 kHz To 4.5/6.3 GHz
• 1 GHz DANL: -162 dBm/Hz
• 1 GHz Phase Noise: -110 dBc/Hz@10 kHz
• Analysis Bandwidth: Up to 25 MHz
• 1000M/100M Ethernet Interface
• Highly Compatible API Interface
• Linux and Windows Operating Systems Are Aupported

Benefits Highlight

NXN series is a versatile and precise tool for real-time spectrum analysis, covering 9 kHz up to 6.3 GHz. It boasts a 6.25 MHz analysis bandwidth and swift 69 GHz/s sweep speed. With a dynamic range of -160 dBm/Hz and robust phase noise performance at -110 dBc/Hz, it ensures accurate and reliable measurements. Ideal for various demanding applications, its compact size and GNSS support make it a dependable choice for professionals on the go.
